Modular multifunction fiber and network interface test platform performs the widest ranging fiber and network tests.
Next Generation Carrier Ethernet Test Solution
MTS-6000A is a compact and lightweight test platform designed for all phases of network lifecycle from the installation to the maintenance of fiber networks. Modular in design, the MTS-6000A offers an extensive portfolio of test functionality for multiple network layers.
A single Multi-Services Application module provides an integrated solution for Ethernet, SONET/SDH, and higher-layer tests. Optical Modules allow thorough testing of short-haul, long-haul, FTTx, CWDM, and high speed 40Gbps networks
Highlights
- Offers maximum usability and minimum footprint with over than 100 applications in a compact, lightweight platform
- Accesses the cloud via Wi-Fi/3G/4G LTE and manages assets and data with Stratasync
- Large compatibility with more than 80 modules and field upgradable options
Applications
- OTDR and power level testing.
- Converged Ethernet/IP networks at 10 Mbps to 10 G interfaces testing and troubleshooting.
- TDM/PDH to SONET/SDH at OC-3/STM-1 to OC-192/STM-64 testing.
- OTN networks installation and maintenance up to 11.1 G interfaces with ODU-0/ODUFlex support for Ethernet/IP client interfaces.
- Dual FC (1, 2, 4, 8, 10 G) testing for service activation and maintenance of SANs and low-latency circuits
- PMD, Spectral Attenuation Profile and Chromatic Dispersion (CD) testing.
- Optical Spectrum Testing
Key Features
- Lightweight platform: only 2.4kg/5.3 lbs.
- Large 8 inch transreflective TFT color display improves viewing under any conditions.
- Intuitive graphical user interface with touchscreen
- Long battery life using smart Lithium ion cell.
- Connection checker with VFL, power meter, ORL and video inspection scope options.
- Built-in optical talkset option for communicating along the fiber.
- Remotely controlled (Ethernet/IP) / WiFi / 3G /4G
- Fast data transfer via USB, Ethernet port and 1GB extended memory.
- GPS option to certify coordinates
Specification
Specifications for Typical 25°C
Display : TFT color, 8.4 in LCD, 800 x 600, high-visibility (standard) Touchscreen,TFT color, 8.4 in LCD, 800 x 600, high-visibility (optional)
Storage and I/O Interfaces
Internal memory 1000 test results
Extended memory (optional) Minimum 1 GB (optional)
2x USB V1.1, 1x RJ45 Ethernet
Power Supply
Battery type Standard removable Li-ion batteries
AC/DC adapter Input 100–240 V, 50–60 Hz,
Output 19 V DC/3.1 A
Operation time Up to 11 hrs with standard display,
Telcordia GR-196-CORE
Bluetooth Class 2, up to 10 m range
Size and Weight : Mainframe with one plug-in module and battery (L x H x W) 285 x 195 x 93 mm (11.2 x 7.7 x 3.7 in) Mainframe only (without battery and module) 2.4 kg (5.3lb)
Power Supply : Battery type Standard removable Li-Ion batteries
Mainframe (with one plug-in module and battery) 3.4 kg (7.5 lb)
Continuous Wave Light Source
Wavelengths (selection) 1310, 1550, and 1625 nm
Size and Weight : Mainframe with two modules and battery (W x H x D) 260 x 135 x 90 mm (10.2 x 5.3 x 3.5 in)
Mainframe only (with battery) 1.4 kg (3 lb)
Mainframe with one module (with battery) <2 kg (<4.35 lb)
Output power level –3.5 dBm
Stability in 15 min ± 0.02 dB
Stability in 8 hrs ± 0.2 dB
Laser safety Class 1M laser
Connector type Field interchangeable
Video Inspection Scope (via USB)
Magnification 250X and 400X, through the USB port
Environmental Specifications
Operating temperature range on mains (no options) : –20 to +50°C (–4 to 122°F)
Operating temperature range (all options) 0 to +40°C(32 to 104°F)
Storage temperature range –20 to +60°C (–4 to 140°F)
Humidity, non-condensing 95%
